Aiming at the shortcomings of hand-held welding laser equipment on the market, such as large size, high power consumption, and inconvenient movement, our company has introduced the latest internal circulation refrigeration method (no external refrigeration) 1500W portable hand-held laser welding machine.
The ZJ-HHW1500-MB integrated portable handheld laser welding machine has a net weight of less than 100 kg, a highly integrated cooling system, and the advantages of integration and portability. Together with the mini handheld welding head independently developed by our company, the performance of the machine More stable, more convenient welding, truly portable laser welding.
Equipment advantages:
1. Highly integrated lightweight design, internal circulating cooling method, smaller product size;
2. Net weight less than 100 kg which greatly reduces the transportation cost and the difficulty of moving;
3. It is more convenient for customers to weld and test on site.
4. Freely replaceable single wobble and double wobble handheld welding head
Specifications(For Reference)
Laser Power | 1500W |
Laser wavelength | 1064nm |
Max modulation frequency | 20K Hz |
Working Temperature | 5-40℃ |
Working humidity | <70% |
Length of fiber cable | 5 meters(Option) |
Power Supply | 1PH / 220V±10% / 50-60Hz |
Cooling Way | Internal recycle water cooling |
Laser Type | Continuous |
Power Range | 10%-100% |
Output fiber core diameter | 50um(20/25/100 option) |
Power Consumption | 6KW |
Patented Handheld Welding Head
Standard Handheld Laser Welding Equipement
Delivery Time
3 Working Days After 100% Payment
Guarantee
2 Years for Laser Source ,1 Year For Other Parts
Handheld Laser Head
Single Wobble And Double Wobble Head( Freely Replaceable)
