200W Suitcase Portable Laser Cleaning Machine

Product Introduction ZJ-CM200-LC suitcase portable Laser cleaning machine is the latest and most cutting-edge surface precision cleaning technology on the market. The high energy efficiency and instant high temperature of the laser are used to produce an explosion-like effect on the surface of...

Send Inquiry

Description

Product Introduction

ZJ-CM200-LC suitcase portable Laser cleaning machine is the latest and most cutting-edge surface precision cleaning technology on the market.

The high energy efficiency and instant high temperature of the laser are used to produce an explosion-like effect on the surface of the product, and the impurities and materials that need to be removed from the surface are stripped and evaporated to obtain a satisfactory high-quality surface treatment effect.

Compared with traditional industrial cleaning methods, laser cleaning has the characteristics of environmental protection, high efficiency, small footprint, high flexibility, and easy operation, and is accepted by more and more customers.

Features

60KG Easy to carry, transport to customer on-site demonstration ;

Non-contact cleaning,no internal stress and deformation;

Lightweight design, high integration, safe operation ;

No need chemical detergent, no consumable ;

Convenient mobile system for 22-inch luggage ;

Universal single phase 220V power supply ,plug and use ;

2D air cooling cleaning head with safety button;

Built-in air cooling system with 6 different laser cleaning models;

Unique external fuse design makes operation more safe and easy to replace.

Applicable materials and industries

1.Rust removing from metal parts ;

2.Weld bead cleaning for stainless steel ,copper ,Aluminium,carbon steel ;

3.Cultural Relics,Sculptures restoration ;

4.Graffiti ,paint removing from heritage building and Stone statue;

5.Wooden antique furniture clean after smoke damage.

Specifications(For reference only)

Laser Power	200W
Laser wavelength	1064nm
Pulse width(ns)	10-350(option)
Pulse repetition frequency(KHZ)	20-2000
Max Single Pulse Energy(MJ)	1
Working Humidity	<70%
Power Supply	1PH / 220V±10% / 50-60HZ / 10A
Power Consumption	2300W
Cooling Way	Air cooling
Laser Type	Pulse Fiber laser
Length of fiber cable(m)	3（option)
Working Humidity	<70%
Working Temperature	5-40°C
Lase Beam Width	Standard 100mm
Laser beam types	6 different types
Cleaning head safety button	Yes
Weight of cleaning head	<1 kg
LED light on head	Yes / 2 pieces
Machine Size	523 x 411 x 685 mm
Size with Plywood box	980 x 670 x 640 mm
Net / Gross Weight	60KG / 80KG
Express chargeable weight	85KG
Emergency Button	Yes
Work indicator	Three colors display Lamp
Operation interface language	English(Option)
Moving Wheels	4 pieces wheels
Shockproof foot pad	4 pieces rubber foot pad
